Self Aligning Ball Bearings 2200 series ball bearing

Self Aligning Ball Bearings2200 series ball bearing

Quantity:
Item:	2200
Availability:





Inquire Add to Basket

Model:
2200
Brand:
SDLLZC
Code:
8482101000

Product Description

Shandong Liulian Bearing Company is a manufacturer deep groove ball bearing，cylindrical roller bearing,spherical roller bearing ,self-aligning ball bearing,thrust ball bearing and linear guides..

Good quality and Short delivery time,many sizes are available in stock,welcome.

Contact Lynn

Email: liyun@sdllbearing.com

Wechat/WhatsApp: +86 18953905063

The self-aligning ball bearing has two structures of cylindrical hole and conical hole, and the material of the cage is steel cage, synthetic resin cage, etc. Its characteristic is that the outer ring raceway is spherical, with automatic centering, which can compensate for errors caused by non-concentricity and shaft deflection, but the relative inclination of the inner and outer rings should not exceed 3 degrees.

Mainly bear radial load, and can bear small axial load at the same time.
The axial displacement of the shaft (housing) is limited within the clearance limit, and it has automatic centering performance.
It allows normal operation under the condition that the inner and outer periphery are relatively inclination.
It is suitable for the parts where the bearing seat hole cannot strictly guarantee the coaxiality.

Application of Self-aligning ball bearings:

Self-aligning ball bearings are suitable for industries such as heavy loads and shock loads, precision instruments, low-noise motors, automobiles, motorcycles, metallurgy, rolling mills, mining, petroleum, papermaking, cement, sugar extraction, and general machinery.

Liulian Bearing Advantage	1.Excellent and high quality control,high speed,low noise,long life
	2.Prompt delivery
	3.Competitive price
	4.Small order accepted
	5.Customers' drawing or samples accepted
	6.OEM service
	7.Professional:many years manufacture bearing

Bearing No.		d(mm)	D(mm)	B(mm)	Bearing No.		d(mm)	D(mm)	B(mm)
1200		10	30	9	1300		10	35	11
1201		12	32	10	1301		12	37	12
1202		15	35	11	1302		15	42	13
1203	1203 K	17	40	12	1303	1303 K	17	47	14
1204	1204 K	20	47	14	1304	1304 K	20	52	15
1205	1205 K	25	52	15	1305	1305 K	25	62	17
1206	1206 K	30	62	16	1306	1306 K	30	72	19
1207	1207 K	35	72	17	1307	1307 K	35	80	21
1208	1208 K	40	80	18	1308	1308 K	40	90	23
1209	1209 K	45	85	19	1309	1309 K	45	100	25
1210	1210 K	50	90	20	1310	1310 K	50	110	27
1211	1211 K	55	100	21	1311	1311 K	55	120	29
1212	1212 K	60	110	22	1312	1312 K	60	130	31
1213	1213 K	65	120	23	1313	1313 K	65	140	33
1214	1214 K	70	125	24	1314	1314 K	70	150	35
1215	1215 K	75	130	25	1315	1315 K	75	160	37
1216	1216 K	80	140	26	1316	1316 K	80	170	39
1217	1217 K	85	150	28	1317	1317 K	85	180	41
1218	1218 K	90	160	30	1318	1318 K	90	190	43
1219	1219 K	95	170	32	1319	1319 K	95	200	45
1220	1220 K	100	180	34	1320	1320 K	100	215	47
1221	1221 K	105	190	36	1322	1322 K	110	240	50
1222	1222 K	110	200	38
1224	1224 K	120	215	42
1226	1226 K	130	230	46

Bearing No.		d(mm)	D(mm)	B(mm)	Bearing No.		d(mm)	D(mm)	B(mm)
2202		15	35	14	2304	2304 K	20	52	21
2203		17	40	16	2305	2305 K	25	62	24
2204	2204 K	20	47	18	2306	2306 K	30	72	27
2205	2205 K	25	52	18	2307	2307 K	35	80	31
2206	2206 K	30	62	20	2308	2308 K	40	90	33
2207	2207 K	35	72	23	2309	2309 K	45	100	36
2208	2208 K	40	80	23	2310	2310 K	50	110	40
2209	2209 K	45	85	23	2311	2311 K	55	120	43
2210	2210 K	50	90	23	2312	2312 K	60	130	46
2211	2211 K	55	100	25	2313	2313 K	65	140	48
2212	2212 K	60	110	28	2314	2314 K	70	150	51
2213	2213 K	65	120	31	2315	2315 K	75	160	55
2214	2214 K	70	125	31	2316	2316 K	80	170	58
2215	2215 K	75	130	31	2317	2317 K	85	180	60
2216	2216 K	80	140	33	2318	2318 K	90	190	64
2217	2217 K	85	150	36	2319	2319 K	95	200	67
2218	2218 K	90	160	40	2320	2320 K	100	215	73
2219	2219 K	95	170	43	2322	2322 K	110	240	80
2220	2220 K	100	180	46
2222	2222 K	110	200	53
